More Efficient and Low-cost RFID Tag Solution

Etag high temperature-resistant labels adopt the material with good resistance of high temperature, including material used in inlay, surface material and glue, which pass through rigorous test. The long-term working temperature of this series of RFID labels is up to 149℃, and short-term working temperature is up to 204℃

• Manufacture labels for photovoltaic component, the product ID number could be wrote into labels to manage and track the photovoltaic components
• Manufacture labels for electronic products like charge bank, even they generate massive heat at working, the high temperature-resistant RFID labels will also work well
• The material adopted by the high temperature-resistant labels is nontoxic, scentless and safe, which could be used for food package.

Manufacture
We usually use below material to make RFID high temperature-resistant labels due to its features. If you ask for other material, please contact us, we are willing to provide customized service for you

Paper or cloth：①Avery high gloss PET (MZ0305) ② Avery matt white PP synthetic paper（BW0052, 58g) ③ Avery matt white bright white PET (MZ0097)
Glue: 3M 467MP double sided tape
Size: 54×86 / 96.5×23.2 / 98.18×12.31 (mm)
Inlay: ①HYD1012A+FM11RF08；②1020239B+SLI-X；③HYD2029+Higgs 3；④RZN-9640+Higgs 3
Print:①PS Intermittent printing ② print with carbon ribbon for variable information

Product	JL-AM22 High Temperature RFID Tags
Example for application	Stick on charge pal shell
*Integrated Circuit(IC)	Alien Higgs-3
*Label Size	3.8*0.913"（96.5*23.2mm）
*Label Material	/
*Label Glue	3M467MP ①Supplied by 3M company ②Excellent adhesion effect, can prevent falling off and excellent waterproof performance, good processing, good temperature resistance, good adhesion;  ③Heat-resistant of 149 ℃ for long time, heat-resistance of 204 ℃ for short time;
*Personalization	/
*Shipping Method	Single row reel form 5,000pcs/roll/inner box, inner box size: 227*227*125mm 4 rolls/carton, carton box size :495*240*280mm Gross weight：14kg/carton
MOQ	20,000pcs
Operating Frequency	840Mhz-960Mhz
International Standards	EPC Class 1 Gen 2
	ISO/IEC 18000-6C
Write Cycle	100,000@25℃，data save 10 years
IC Memory	96-480 bits EPC,512bits user,32 bits TID,64 bits unique TID,32 bits access password,32bits kill password
Comments	Dear: all marked ' * ' could be customized ,please take a note

Product	JL-AM23 High Temperature RFID Tags
Example for application	Asset management; logistics
Read Range	up to 10cm
*Integrated Circuit(IC)	FUDAN FM11RF08
*Label Size	2.126*3.386"（54*86mm)
*Label Material	Avery dennison white bright PET（MZ0305) ①Excellent resistance to gas, water, oil ;  ②Excellent resistance to high and low temperature，-50℃-+90℃;  ③Good folding resistance;  ④Non-toxic, tasteless, good hygiene and safety, can be directly used in food packaging
*Label Glue	3M467MP ①Supplied by 3M company ②Excellent adhesion effect, can prevent falling off and excellent waterproof performance, good processing, good temperature resistance, good adhesion;  ③Heat-resistant of 149 ℃ for long time, heat-resistance of 204 ℃ for short time
*Personalization	3M467MP ①Supplied by 3M company ②Excellent adhesion effect, can prevent falling off and excellent waterproof performance, good processing, good temperature resistance, good adhesion;  ③Heat-resistant of 149 ℃ for long time, heat-resistance of 205 ℃ for short time;
*Shipping Method	We can HEI ECO print for you;
*Shipping Method	Single row reel form 1,000pcs/roll/inner box, inner box size: 227*227*85mm 4 inner boxes/carton, carton box size :495*240*200mm Gross weight：8kg/carton
MOQ	24,000pcs
Operating Frequency	13.56MHz
International Standards	ISO 14443
Write Cycle	100,000@25℃，data save 10 years
IC Memory	8K bits user memory
Comments	Dear: all marked ' * ' could be customized ,please take a note

Product	JL-AM24 High Temperature RFID Tags
Application Areas	Libraries; asset and document tracking; industrial applications
Read Range	1.5m by fixed reader, 30dBm
*Integrated Circuit(IC)	NXP SLI-X
*Label Size	2.126*3.386"（54*86mm)
*Label Material	Avery dennison 58g Sub white PP（BW0052)  ①Good environmental protection performance,easy to recover and waste treatment;  ②Good stability;  ③Corrosion resistance, durability, 100% waterproof, anti-chemical and anti-grease, good processing performance;  ④High strength;
*Label Glue	3MVHB9460 ①Supplied by 3M company; ②Water resistance, heat resistance, strong adhesion, excellent weather resistance, chemical solvent resistance, aging resistance and so on
*Personalization	We can HEI ECO print for you
*Shipping Method	Single row reel form 1,000pcs/roll/inner box, inner box size: 227*227*85mm 4 inner boxes/carton, carton box size :495*240*200mm Gross weight：8kg/carton
MOQ	24,000pcs
Operating Frequency	13.56MHz
International Standards	ISO 15693
Write Cycle	100,000@25℃，data save 10 years
IC Memory	896 bits user memory
Comments	Dear: all marked ' * ' could be customized ,please take a note
